Description
The Motorola DS9208 general purpose presentation scanner delivers the blazing speed typical of laser scanners on both 1D and 2D barcodes, accommodating 2D barcodes without sacrificing scanning quality or performance. Users never need to take time to align the barcode with the scanner or pause between scans. Since the DS9208 can scan barcodes printed on paper labels or on mobile phone displays, users can drive revenue by attracting the millions of customers who are using their cell phones to better manage their lives. Retailers can accommodate customers who download mobile coupons, mobile loyalty cards and more. Quick service restaurants can accept mobile coupons at the register. Hotels can allow guests to use electronic loyalty cards stored on their cell phones, eliminating the need to carry physical cards. And since theaters, theme parks and stadiums can scan mobile tickets as easily as a paper ticket, they can offer customers an added convenience: paperless ticketing.

Scans 1-D, 2-D and PDF417 barcodes on paper, mobile phones and computer displays
Scan virtually any barcode on any medium; supports the technology your customers are embracing ? mobile barcodes

Sleek design and small footprint
Perfect in the most design conscious environments; most compact device in its class, fits in the most space constrained areas

Handheld and hands-free modes
Dual mode functionality saves time; keeps lines moving; reduces the need to lift heavy items

Picklist mode
Select and scan a single barcode from a barcode menu or ?picklist? ? ideal for items that are too small for barcode labels

Driver?s license parsing (optional)
Captures information from driver?s licenses, enabling fast auto-population of loyalty and credit card applications, increasing enrollment

Multi-code mode
Allows simultaneous scanning of a group of barcodes and reports only the selected barcode(s) in a pre-selected order

Industry-first spherical exit window
Improves scanning performance by minimizing stray light and reducing reflections to the imaging sensor

Omnidirectional scanning; supports all common interfaces
Eliminates the need to align barcode and scanner; easy integration into current or future environments

5 ft./1.5 m drop spec and recessed exit window
Increased durability; prevents nicks and scratches that could degrade performance

Compatible with 123Scan2 and Remote Scanner Management (RSM)
Reduces management time and cost, from initial configuration to day-to-day management

Specs:

Imaging characteristics

Graphics formats supported
Bitmap, JPEG, TIFF

Performance characteristics

Scan pattern
Omnidirectional

Decode capability
1-D/2-D/PDF417, See data sheet for full list of supported symbologies

Interfaces supported
IBM, Keyboard wedge, RS-232, Synapse, USB

Technology
Imager

Physical characteristics

Color
Twilight black

Weight
10 oz./284 g

Voltage and current1
Idle: 5 +/-10% VDC @ 150ma average Scanning: 5 +/-10% VDC @ 230ma average

Corded
Yes

Dimensions
5.512 in. H x 3.232 in. W x 3.150 in. D /14.0 cm H x 8.21 cm W x 8.0 cm D

Power source
Host power or external power supply (depends on host type)

Hands-free
Yes

Regulatory specifications

Environmental
RoHS Directive 2002/95/EEC

Electrical safety
UL 60950-1, C22.2 No. 60950-1, EN 60950-1, IEC 60950-1

EMI/RFI
EN 55022, FCC Part 15 Class B, ICES 003 Class B, EN 55024
