“Dahua DH-IPC-HFW3449EP-AS LEDDahua 4MP Full-color Warm LED Fixed-focal Bullet WizSense Network Camera “
| Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Image Sensor | 1/2.7ā4Megapixel progressive CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. Resolution | 2688 (H) Ć1520 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ROM | 128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| RAM | 512 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Electronic Shutter Speed | Auto/Manual 1/3 sā1/100, 000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Min. Illumination | 0.003 Lux @ F1.0 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| S/N Ratio | > 56 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illumination Distance | 30 m (98.4 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illuminator On/Off Control | Auto/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illuminator Number | 1 (warm LED) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pan/Tilt/Rotation Range | Horizontal:0Ā°-360Ā°;Vertical:0Ā°-90Ā°;Rotation:0Ā°-360Ā° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Lens Type | Fixed-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Mount Type | M12 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Focal Length | 2.8 mm; 3.6 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. Aperture | F1.0 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Field of View | 2.8 mm: Horizontal 103Ā° Ć vertical 53Ā° Ć diagonal 122Ā° 3.6 mm: Horizontal 80Ā° Ć vertical 43Ā° Ć diagonal 95Ā° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Iris Type | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Close Focus Distance | 2.8 mm: 1.2 m (3.9 ft) 3.6 mm: 2.4 m (7.9 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 2.8mm | 56.0 m (183.7 ft) | 22.4 m (73.5 ft) | 11.2 m (36.7 ft) | 5.6 m (18.4 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 3.6mm | 80.0 m (262.5 ft) | 32.0 m (105.0 ft) | 16.0 m (52.5 ft) | 8.0 m (26.3 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Professional, Intelligent | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Perimeter Protection | Tripwire, intrusion (Recognition of vehicle and people) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG(only supported by the sub stream) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Smart Codec | Smart H.265+/ Smart H.264+ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Video Frame Rate | Main stream (2688 Ć 1520 @ 1ā25/30 fps) sub stream (704 Ć 576 @ 1ā25/704 Ć 480 @ 1-30 fps) third stream (1280 Ć 720 @ 1ā25/30 fps) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Stream Capability | 3 streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Resolution | 4M (2688 Ć 1520); 3M (2304 Ć 1296); 1080p (1920 Ć 1080); 1.3M (1280 Ć 960); 720p (1280 Ć 720); D1 (704 Ć 576/704 Ć 480); VGA (640 Ć 480); CIF (352 Ć 288/352 Ć 240) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Bit Rate Control | CBR; VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Video Bit Rate | H.264: 3 kbpsā8192 kbps H.265: 3 kbpsā8192 kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Day/Night | Color/B/W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| BLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| WDR | 120 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| White Balance | Auto/natural/street lamp/outdoor/manual/regional custom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Gain Control | Auto/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Noise Reduction | 3D DNR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Motion Detection | OFF/ON (4 areas, rectangular) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Region of Interest (RoI) | Yes (4 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Smart Illumination | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Image Rotation | 0Ā°/90Ā°/180Ā°/270Ā° (Support 90Ā°/270Ā° with 1920 Ć 1080 resolution and lower.) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Mirror | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Privacy Masking | 4 areas | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Audio | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Built-in MIC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Audio Compression | G.711a; G.711Mu; G726; AAC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alarm Event | No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; input abnormal; intensity change; tripwire; intrusion; SMD | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Network | RJ-45 (10/100 Base-T) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| SDK and API | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Protocol | IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Interoperability | ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Scene self-adaptation | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| User/Host | 20 (Total bandwidth: 64M.) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Storage | FTP; SFTP; Micro SD Card (support max. 256 G); Dahua Cloud; NAS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Browser | IE: IE8; IE9; IE11 Chrome Firefox | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Management Software | Smart PSS; DSS; DMSS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Mobile Phone | IOS; Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Certification | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Certifications | CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Audio Input | 1 channel (RCA port) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Audio Output | 1 channel (RCA port) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alarm Input | 1 channel in: 5mA 3Vā5V DC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alarm Output | 1 channel out: 300mA 12V DC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Supply | 12V DC/PoE | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Consumption | < 8.4W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Environment | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Operating Conditions | -40Ā°C to +60Ā°C (-40Ā°F to +140Ā°F)/less than 95% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Storage Conditions | -40Ā°C to +60Ā°C (-40Ā°F to +140Ā°F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Protection Grade | IP67 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Structure | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Casing | Metal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Dimensions | 192.7 mm Ć 70.5 mm Ć 66.4 mm (632.2" Ć 231.3" Ć 217.8") (L Ć W Ć H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Net Weight | 590 g (1.3 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Gross Weight | 780 g (1.7 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
“Hikvision 7232HGHI-K232-ch 1080p Lite 1U H.265 DVR 32 channels and 2 HDDs 1U DVR”
- Recording
- Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding Resolution1080p lite/720p/VGA/WD1/4CIF/CIF
- Frame Rate
Main stream:
For 1080p stream access: 1080p lite/720p lite/WD1/4CIF/VGA@15fps; CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/WD1/4CIF/VGA@15fps; CIF@25fps (P)/30fps (N)
For standard definition stream access: WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
For 1080p and 720p stream access: CIF/QVGA@15fps
For standard definition stream access: CIF/QVGA@25fps (P)/30fps (N)
- Video Bitrate32 Kbps to 4 Mbps
- Dual-StreamSupport
- Stream TypeVideo, Video & Audio
- Audio CompressionG.711u
- Audio Bitrate64 Kbps
- Video And Audio
- IP Video Input
2-ch (up to 18-ch)
Up to 5 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
- Analog Video Input
32-ch
BNC interface (1.0 Vp-p, 75 Ī©), supporting coaxitron connection
- HDTVI Input1080p25, 1080p30, 720p25, 720p30
- AHD Input1080p25, 1080p30, 720p25, 720p30
- HDCVI Input1080p25, 1080p30, 720p25, 720p30
- CVBS InputPAL/NTSC
- HDMI Output1-ch, 1920 Ć 1080/60Hz, 1280 Ć 1024/60Hz, 1280 Ć 720/60Hz, 1024 Ć 768/60Hz
- VGA Output1-ch, 1920 Ć 1080/60Hz, 1280 Ć 1024/60Hz, 1280 Ć 720/60Hz, 1024 Ć 768/60Hz
- CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ī©)
- Audio Input1-ch, RCA (2.0 Vp-p, 1 KĪ©)
- Audio Output1-ch, RCA (Linear, 1 KĪ©)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KĪ©) (using the first audio input)
- Synchronous Playback16-ch
- Network
- Remote Connection128
- Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnPā¢, HTTPS, ONVIF
- Network Interface1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
- Auxiliary Interface
- SATA2, SATA interface
- CapacityUp to 10 TB capacity for each disk
- USB Interface
Front panel: 1 Ć USB 2.0
Rear panel: 1 Ć USB 3.0
- General
- Power Supply12 VDC, 3.2 A
- Consumptionā¤ 18 W
- Working Temperature-10 Ā°C to 55 Ā°C (14 Ā°F to 131 Ā°F)
- Working Humidity10% to 90%
- Dimension (W Ć D Ć H)380 Ć 320 Ć 48 mm (10.2 Ć 8.7 Ć 1.8 inch)
- ā¤ 2.2 kg (4.9 lb)
“Hikvision 7232HQHI-K2(STD)32-ch 1080p 1U H.265 DVR 32 channels and 2 HDDs 1U DVR”
- Perimeter Protection
- Line Crossing Detection/Intrusion Detection
2-ch
Enhanced VCA mode on: 4-ch
- Recording
- Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding Resolution
When 1080p lite mode is not enabled:
4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF
When 1080p Lite mode is enabled:
4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
- Frame Rate
Main stream:
When 1080p Lite mode not is enabled:
For 4 MP stream access:
4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps
For 1080p stream access:
1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode is enabled:
4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
- Video Bitrate32 Kbps to 6 Mbps
- Dual-StreamSupport
- Stream TypeVideo, Video & Audio
- Audio CompressionG.711u
- Audio Bitrate64 Kbps
- Video And Audio
- IP Video Input
2-ch (up to 34-ch)
Enhanced IP mode on:
8-ch (up to 40-ch), each up to 4 Mbps
Up to 6 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
- Analog Video Input
32-ch
BNC interface (1.0 Vp-p, 75 Ī©), supporting coaxitron connection
- Incoming BandwidthEnhanced IP mode on: 160 Mbps
- HDTVI Input
4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
*: The 3 MP signal input is only available for channel 1/2/3/4.
- AHD Input4 MP, 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input1080p25, 1080p30, 720p25, 720p30
- CVBS InputPAL/NTSC
- HDMI Output
1-ch, 4K (3840 Ć 2160)/30Hz, 2K (2560 Ć 1440)/60Hz, 1920 Ć 1080/60Hz,
1280 Ć 1024/60Hz, 1280 Ć 720/60Hz, 1024 Ć 768/60Hz
- VGA Output1-ch, 1920 Ć 1080/60Hz, 1280 Ć 1024/60Hz, 1280 Ć 720/60Hz, 1024 Ć 768/60Hz
- CVBS Output
1-ch, BNC (1.0 Vp-p, 75 Ī©),
resolution: PAL: 704 Ć 576, NTSC: 704 Ć 480
- Audio Input1-ch, RCA (2.0 Vp-p, 1 KĪ©)
- Audio Output1-ch, RCA (Linear, 1 KĪ©)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KĪ©) (using the first audio input)
- Synchronous Playback16-ch
- Network
- Remote Connection128
- Total Bandwidth128 Mbps
- Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnPā¢, HTTPS, ONVIF
- Network Interface
1,
RJ45 10M/100M/1000M self-adaptive Ethernet interface
- Auxiliary Interface
- Serial InterfaceRS-485 (half-duplex)
- SATA2 SATA interfaces
- CapacityUp to 10 TB capacity for each disk
- Alarm In/OutN/A
- USB Interface
Front panel: 1 Ć USB 2.0
Rear panel: 1 Ć USB 3.0
- General
- Power Supply12 VDC, 4.5 A
- Consumptionā¤ 65 W (without HDD)
- Working Temperature-10 Ā°C to +55 Ā°C (+14 Ā°F to +131 Ā°F)
- Working Humidity10% to 90%
- Dimension (W Ć D Ć H)380 Ć 320 Ć 48 mm (15.0 Ć 12.6 Ć 1.9 inch)
- ā¤ 2 kg (4.4 lb)
“Hikvision DS-2CE17D0T-IT3F(3.6mm)(O-STD) (C )2 MP Fixed Bullet Camera High quality imaging with 2 MP, 1920 ? 1080 resolution”
- Camera
- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) Ć 1080 (V)
- Min. Illumination0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time
PAL: 1/25 s to 1/50,000 s
NTSC: 1/30 s to 1/50,000 s
- Day & NightICR
- Angle AdjustmentPan: 0 to 360Ā°, Tilt: 0 to 180Ā°, Rotation: 0 to 360Ā°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 106.4Ā°, vertical FOV: 57.9Ā°, diagonal FOV: 124.6Ā°
3.6 mm, horizontal FOV: 79.6Ā°, vertical FOV: 43.5Ā°, diagonal FOV: 93.7Ā°
6 mm, horizontal FOV: 51.9Ā°, vertical FOV: 30Ā°, diagonal FOV: 58.8Ā°
8 mm, horizontal FOV: 39.9Ā°, vertical FOV: 21.9Ā°, diagonal FOV: 46.5Ā°
12 mm, horizontal FOV: 24.6Ā°, vertical FOV: 13.9Ā°, diagonal FOV: 28.1Ā°
- Lens MountM12
- Image
- Image Parameters SwitchSTD/HIGH-SAT
- Image SettingsBrightness, Sharpness, Smart IR
- Frame Rate
TVI: 1080P@30fps, 1080P@25fps
CVI: 1080P@30fps, 1080P@25fps
AHD: 1080P@30fps, 1080P@25fps
CVBS: PAL/NTSC
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementDWDR/BLC/HLC/Global
- Noise ReductionYes
- White BalanceAuto/Manual
- AGCYes
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- Material
Front Cover: Metal
Main Body: Plastic
- Dimension78.9 mm Ć 75.4 mm Ć 216.6 mm (3.10" Ć 2.97" Ć 8.53")
- Approx. 320 g (0.71 lb.)
- Operating Condition-40 Ā°C to 60 Ā°C (-40 Ā°F to 140 Ā°F), humidity: 90% or less (non-condensation)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power Supply12 VDC Ā± 25%
- ConsumptionMax. 3.9 W
- IR RangeUp to 40 m
- Approval
- ProtectionIP67
“Hikvision DS-7104HQHI-K1(S)4-ch 1080p Mini 1U H.265 DVR 4 channels and 1 HDD mini size DVR”
- Recording
- Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding Resolution
When 1080p Lite mode is not enabled:
4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF;
When 1080p Lite mode is enabled:
4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
- Frame Rate
Main stream:
When 1080p Lite mode is not enabled:
For 4 MP stream access:
4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps
For 1080p stream access:
1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode is enabled:
4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
- Video Bitrate32 Kbps to 6 Mbps
- Dual-StreamSupport
- Stream TypeVideo, Video & Audio
- Audio CompressionG.711u
- Audio Bitrate64 Kbps
- Video And Audio
- IP Video Input
1-ch (up to 5-ch)
Enhanced IP mode on:
2-ch (up to 6-ch), each up to 4 Mbps
Up to 6 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
- Incoming Bandwidth24 Mbps
- Analog Video Input
4-ch
BNC interface (1.0 Vp-p, 75 Ī©), supporting coaxitron connection
- HDTVI Input
4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
*: The 3 MP signal input is only available for channel 1 of DS-7104HQHI-K1.
- AHD Input4 MP, 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input4 MP, 1080p25, 1080p30, 720p25, 720p30
- CVBS InputSupport
- VGA Output1-ch, 1920 Ć 1080/60Hz, 1280 Ć 1024/60Hz, 1280 Ć 720/60Hz, 1024 Ć 768/60Hz
- HDMI Output1-ch, 1920 Ć 1080/60Hz, 1280 Ć 1024/60Hz, 1280 Ć 720/60Hz, 1024 Ć 768/60Hz
- Audio Input
1-ch, RCA (2.0 Vp-p, 1 KĪ©)
4-ch via coaxial cable
- Audio Output1-ch, RCA (Linear, 1 KĪ©)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KĪ©) (using the first audio input)
- Synchronous Playback4-ch
- Network
- Total Bandwidth72 Mbps
- Remote Connection32
- Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnPā¢, HTTPS, ONVIF
- Network Interface1, RJ45 10M/100M self-adaptive Ethernet interface
- Auxiliary Interface
- SATA1 SATA interface
- CapacityUp to 6 TB capacity for each disk
- Alarm In/OutN/A
- USB InterfaceReal panel: 2 Ć USB 2.0
- General
- Power Supply12 VDC, 1.5 A
- Consumptionā¤ 8 W
- Working Temperature-10 Ā°C to +55 Ā°C (+14 Ā°F to +131 Ā°F)
- Working Humidity10% to 90%
- Dimension (W Ć D Ć H)200 Ć 200 Ć 45 mm (7.9 Ć 7.9 Ć 1.8 inch)
- ā¤ 1 kg (2.2 lb)
“Hikvision DS-7204HUHI-K1/E(STD)(S)4-ch 5 MP 1U H.265 DVR 4 channels and 1 HDD 260 case DVR”
- Recording
- Encoding Resolution
When 8 MP Lite mode is not enabled:
8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
When 8 MP Lite mode is enabled:
8 MP Lite/5 MP/4 MP/3MP/1080P/720P/WD1/4CIF/VGA/CIF
- Video Bit Rate32 Kbps to 10 Mbps
- Frame Rate
Main stream:
When 8 MP Lite mode is not enabled:
8 MP@8 fps/5 MP@12 fps/3K@12 fps/4 MP@15 fps/3 MP@18 fps
1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
*: 8 MP@8 fps is only available for channel 1 of DS-7204HUHI-K1/E.
When 8 MP Lite mode is enabled:
8 MP Lite/5 MP@12 fps/4 MP/3MP/1080P/720P/WD1/4CIF/VGA/CIF@15 fps
*: 8 MP Lite is only available for DS-7204HUHI-K1/E.
Sub-stream:
WD1/4CIF/CIF@25fps (P)/30fps (N)
- Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Dual StreamSupport
- Stream TypeVideo, Video & Audio
- Audio CompressionG.711u
- Audio Bit Rate64 Kbps
- Video And Audio
- Audio Input1-ch, RCA (2.0 Vp-p, 1 KĪ©)ļ¼4-ch via coaxial cable
- Audio Output1-ch, RCA (Linear, 1 KĪ©)
- Synchronous Playback4-ch
- IP Video Input
2-ch (up to 6-ch)
Enhanced IP mode on:
4-ch (up to 8-ch), each up to 4 Mbpsļ¼ Up to 8 MP resolutionļ¼ Support H.265+/H.265/H.264+/H.264 IP cameras
Enhanced IP mode on:
4-ch (up to 8-ch), each up to 4 Mbps
Up to 8 MP resolution;Support H.265+/H.265/H.264+/H.264 IP cameras
- HDTVI Input8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
- HDCVI Input5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
- CVBS InputPAL/NTSC
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KĪ©) (using the first audio input)
- Analog Video Input4-ch;BNC interface (1.0 Vp-p, 75 Ī©), supporting coaxitron connection
- AHD Input5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
- CVBS OutputN/A
- HDMI/VGA Output
HDMI:1-ch, 1920 Ć 1080/60Hz, 1280 Ć 1024/60Hz, 1280 Ć 720/60Hz, 1024 Ć 768/60Hz HDMI and VGA simultaneous output
VGA:1-ch, 1920 Ć 1080/60Hz, 1280 Ć 1024/60Hz, 1280 Ć 720/60Hz, 1024 Ć 768/60Hz
- Network
- Network ProtocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnPā¢, HTTPS, ONVIF
- Remote Connections32
- Network Interface1, RJ45 10M/100M self-adaptive Ethernet interface
- Auxiliary Interface
- CapacityUp to 10 TB capacity for each disk
- Serial InterfaceN/A
- USB Interface2 Ć USB 2.0
- Alarm In/OutN/A
- SATA1 SATA interface
- General
- Consumption(Without HDD)ā¤ 6 W
- Working Humidity10% to 90%
- Power Supply12 VDC
- Working Temperature-10 Ā°C to +55 Ā°C (+14 Ā°F to +131 Ā°F)
- Dimensions(W Ć D Ć H)265 Ć 225 Ć 48 mm (10.4 Ć 8.9 Ć 1.9 inch)
- Weights (Without HDD)ā¤ 1.6 kg (3.5 lb)
“Hikvision DS-7216HUHI-K2(STD)(S)16-ch 5 MP 1U H.265 DVR 16 channels and 2 HDDs 1U DVR”
- Recording
- Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding Resolution8 MP/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
- Frame RateMain stream: ,8 MP@8fps/5 MP@12fps/4 MP@15fps/3 MP@18fps,1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),Sub-stream: ,WD1/4CIF/CIF@25fps (P)/30fps (N)
- Video Bit Rate32 Kbps to 10 Mbps
- Dual StreamSupport
- Stream TypeVideo, Video & Audio
- Audio CompressionG.711u
- Audio Bit Rate64 Kbps
- Video And Audio
- IP Video Input16-ch (up to 32-ch) Up to 8 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
- Analog Video Input16-ch BNC interface (1.0 Vp-p, 75 Ī©), supporting coaxitron connection
- AHD Input5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input4 MP, 1080p25, 1080p30, 720p25, 720p30
- CVBS InputPAL/NTSC
- Audio Input4-ch, RCA (2.0 Vp-p, 1 KĪ©)
- Audio Output1-ch, RCA (Linear, 1 KĪ©)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KĪ©) (using the first audio input)
- Synchronous Playback16-ch
- HDTVI Input8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
- VGA/HDMI OutputVGA: 1-ch, 1920 Ć 1080/60Hz, 1280 Ć 1024/60Hz, 1280 Ć 720/60Hz, 1024 Ć 768/60Hz,HDMI: 1-ch, 4K (3840 Ć 2160)/30Hz, ,2K (2560 Ć 1440)/60Hz,,1920 Ć 1080/60Hz, 1280 Ć 1024/60Hz, ,1280 Ć 720/60Hz, 1024 Ć 768/60Hz
- CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ī©),
- Network
- Remote Connections128
- Network ProtocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnPā¢, HTTPS, ONVIF
- Network Interface1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
- Auxiliary Interface
- SATA2 SATA interfaces
- CapacityUp to 10 TB capacity for each disk
- Alarm In/Out16/4
- USB InterfaceFront panel: 1 Ć USB 2.0,Rear panel: 1 Ć USB 3.0
- Serial InterfaceRS-485 (half-duplex)
- General
- Power Supply12 VDC
- Working Temperature-10 Ā°C to +55 Ā°C (+14 Ā°F to +131 Ā°F)
- Working Humidity10% to 90%
- Dimensions (W Ć D Ć H)380 Ć 320 Ć 48 mm (15.0 Ć 12.6 Ć 1.9 inch)
- Consumption (Without HDD)ā¤ 25 W
- Weights (Without HDD)ā¤ 2 kg (4.4 lb)
10 amp (Power supply 12 v)
Product details of AC DC 12V 10 amp 120W Universal Regulated Switching Power Supply 12V 10A
- Output Voltage:12V DC
- Power Max:120W
- Output Current:10A
- Products size about (L x W x H): 199 x 98 x 42 mm.
- Protection:Shortage Protection, Overload Protection, Over Voltage Protection.
- Widely used in Industrial automation, LED display, communications, CCTV etc.
10 AMP JALI (Power supply 12 v)
15 amp (Power supply 12 v)
2 amp(Power supply 12 v)
About this item
- 12V 2A Switching Power Supply Adapter 2 Pack
- Input Voltage: 100-240V AC; Output Voltage: 12V DC 2000 mA
- Plug Type : 5.5x2.1mm DC Power US Wall Plug
- Idea for CCTV Camera, Audio Amplifier, HUB, Router and Low Voltage Single Color 3528/5050 LED Strip Lights
- 3 Foot Long Cable and 2 Years Warranty
[ti_wishlistsview]
